KI-WON Steam Jet Ejector for Steam Power Plant

Efficiency of turbine is controlled by vacuum of turbine discharge side as the bellow Figure 10. In this system, steam jet ejector is excellent to remove non-condensable gas and to keep condensation pressure of the main condenser. The most common applications are hogging and holding steam jet vacuum system
